Bluetti AC200P L Power Station

The Bluetti AC200P L Power Station from the premium series is an upgrade of the already impressive Bluetti AC200MAX model. This portable power station with 2400W continuous power provides unparalleled access to stored energy, ideal for adventure travel, campers, in off-grid situations, tiny cottages, events or as an emergency power supply in the event of a power outage. Equipped with a robust 2304Wh LFP battery and an advanced Battery Management System (BMS), the AC200P L guarantees optimal performance and a long lifespan of up to ten years.

The battery capacity of AC200P L can be expanded with and the new B300K battery which can increase the power capacity to an impressive 8,448Wh. This modular expandability provides flexibility in energy management.

The AC200P L has an inverter that can continuously deliver 2400W of power. This makes it possible to connect 95% of household appliances to the AC200P L. With the "Power Lift Mode", the peak power can reach 3600W for up to 5 seconds

With the revolutionary fast charging function, the AC200P L can be charged from 0 to 80% in just 60 minutes. This fast charging capacity, combined with a maximum output of 2400W, ensures that the station can be charged quickly, even during the final preparations for a trip. For less urgent situations, the charging speed can be adjusted to a standard or quiet mode, which contributes to the extension of battery life.

Advantages of the Bluetti AC200P L

Extensive energy storage: The Bluetti AC200P L offers a significant 2304Wh energy storage capacity, allowing users to enjoy long-term power supply without frequent recharge needs. This makes it ideal for longer journeys, emergency power supplies, and reducing reliance on the grid.
Power Lifting Mode: The AC200P L has 2400W continuous power but with Power Lifting Mode the peak power is 3600W. This is ideal when you want to connect devices such as kettle, heaters, kettle or air conditioner to the AC200P L.
Bluetti D40 DC-DC Battery Charger: Combine this Bluetti D40 DC-DC Battery Charger with the Bluetti AC200P L Power Station and solar panels, the D40 eliminates the complexity of installations, making it an ideal choice for mobile use and remote locations.
48V DC port: Equipped with a 48V 8A output, which can be useful for charging an RV Life battery with D40, for example.
Modular Expandability: With the ability to link to additional battery modules like the new B300K battery, the AC200P L offers customizable storage options that meet diverse energy needs and scenarios, from everyday use to emergency situations.
Fast charging technology: The AC fast charging function of the AC200P L ensures a fast charging time, allowing the station to be charged up to 80% within an hour. This is especially useful for users who need to get back on the road quickly or who want to minimize the time between charges. Of course, it is also possible to charge the AC200P L via max 1200W solar panels.
Versatile energy solution: Suitable for a wide range of appliances and applications, from home appliances to power tools, the AC200P L offers flexibility and reliability, making it an essential companion for both indoor and outdoor use.
Bluetti APP WiFi/Bluettoth: The BLUETTI app allows users to easily adjust and monitor their power settings, ensuring a seamless and user-friendly experience.
Durable and reliable: The AC200P L is designed with durability in mind, with a rugged construction and materials that can withstand a variety of environmental factors, making it a reliable choice for any adventure or situation.
Environmentally friendly: By maximizing the use of solar energy, the AC200P L contributes to a more sustainable future, allowing users to reduce their carbon footprint and contribute to a greener planet.

The BLUETTI D60L is an advanced 560W alternator charger that charges your BLUETTI power stations up to six times faster than traditional car chargers. It makes efficient use of your vehicle's alternator and is compatible with 95% of other brands of power stations. With the BLUETTI app, you can easily monitor and adjust the charging status and output voltage via your smartphone. In addition, the D60L features automatic detection for starting and stopping the vehicle, a cooling fan for stable operation, and built-in protections to protect both your vehicle and your power station while charging. Click here for more info!

Bluetti AC200P L in combination with Bluetti D40 DC-DC Battery Charger

Designed for seamless collaboration with the Bluetti AC200P L Power Station and solar panels, the D40 eliminates the complexity of installations, making it an ideal choice for mobile use and remote locations. In addition, Suitable for a wide range of battery types, including LiFePO₄, AGM/gel, lead-acid and calcium, the D40 offers flexibility in use.

Bluetti D40 DC-DC in combination with Bluetti AC200P L Power Station.

With a TT-30 port, you can power your RV directly from the AC200PL, making it a reliable source of energy on wheels. You can charge your laptop, mobile phone and camera while enjoying your meal in style.



Technical Information for Bluetti AC200P L

General:

Brand:
Bluetti

Article number:
P-AC200PL-EU-GY-BL-010

Capacity:
2,304Wh
Cell type:
LiFePO4 (Lithium Iron Phosphate)

AC + DC Input:
Maximum 2,400W

Charging temperature:
0°C to 40°C / 32°F to 104°F
Discharge temperature:
-20°C to 40°C / -4°F to 104°F

Exit:

Total power:
2,400W (3600W peak power, 5 sec.)
Tension:
4x 230V

Solar panels:
1200W 12V - 145V (max 15A)

Car port:
1x 12VDC / 10A

USB-A:
2x: 18W maximum
USB-C:
2x 100W PD Port

48V DC Port:
1x 48VDC / 8A

AC Input:

Tension:
230VAC

Stream:
Maximum 20A

UPS changeover time:
≤20ms

Remainder:

Connectivity:
WiFi / Bluetooth

Dimensions
(L x W x H): 420mm x 280mm x 366.5mm / 16.5in x 11in x 14.4in

Net weight:
28.8kg / 63.5lbs

Certifications:
UN38.3, UL, FCC, IC, CE, ROHS, TELEC, PSE, RCM, LOA, ICASA



What's in the box:

Bluetti AC200P L Power Station
2400W AC AC Power Adapter
1200W Solar charging cable of 1.5 meters
12V Car Charger (Car Plug to DC 7909 connector)
Manual

Documents Bluetti AC200P L:

AC200P L-manual

AC200P L-manual

Premium Series Portable Power Station

Premium Series Portable Power Station
